G/EPON DUAL MODE ONU 1GE+3FE +2POTS+2.4G WiFi+USB for FTTx Solution

Ask Lasest Price
Brand Name :	V-solution
Model Number :	HG326R
Price :	Negoticable
Payment Terms :	Negociable
Supply Ability :	10000 pcs/day
Delivery Time :	3-5 days

Add to Cart

Product Details
Company Profile

G/EPON DUAL MODE ONU 1GE+3FE +2POTS+2.4G WiFi+USB for FTTx Solution

Product Description

HG326R G/EPON with 1GE+3FE/4GE+2POTS+WiFi+USB ONU support Dual mode (EPON and GPON), It can also be applied to a wide temperature environment, and also has a powerful firewall function.

Hg326R G/EPON ONU meets telecom operators FTTO (office), FTTD (Desk), FTTH(Home) broadband speed, SOHO broadband access, video surveillance and other requirements and design a GPON/EPON Gigabit Ethernet products. The box is based on the mature Gigabit GPON/EPON technology, highly reliable and easy to maintain, with guaranteed QOS for different service. And it is fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.

G/EPON 1GE+3FE/4GE+2POTS+WiFi+USB ONU

Key Features

Dual Mode (can access GPON/EPON OLTs).
Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade, etc.
Integrated OAM remote configuration and maintenance function.
Support rich QinQ VLAN functions and IGMP Snooping multicast features.
Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.
Support 802.11n WiFi(2T2R) function.
Support NAT, Firewall function.
Support IPv4 and IPv6 dual stack.
Integrated line testing compliant with GR-909 on POTS.

Specifications

Technical item	HG326R
PON interface	1 G/EPON port (EPON PX20+ and GPON Class B+)
	Wavelength: Tx1310nm, Rx 1490nm
	SC/UPC connector
	Receiving saturation:≥-8dBm
	Receiving sensitivity: ≤-28dBm
	Transmitting optical power: 0~+4dBm
	Transmission distance: 20KM
LAN interface	1 x 10/100/1000Mbps and 3 x 10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
Wireless	Compliant with IEEE802.11b/g/n
	Operating frequency: 2.400-2.4835GHz
	support MIMO, rate up to 300Mbps
	2T2R,2 external antenna 5dBi
	Support: multiple SSID
	Channel:13
	Modulation type: DSSS,CCK and OFDM
	Encoding scheme: BPSK,QPSK,16QAM and 64QAM
POTS interface	2 FXS, RJ11 connector
	Support: G.711/G.723/G.726/G.729 codec
	Support: T.30/T.38/G.711 Fax mode, DTMF Relay
	Line testing according to GR-909
USB interface	USB 2.0
LED	PWR, PON, LOS, WAN, WiFi, FXS1~2, ETH1~4, WPS, USB
Operating condition	Temperature: 0℃～+50℃
Storing condition	Humidity: 5%～90%(non-condensing)
	Temperature : -30℃～+75℃
	Humidity :5%～90%(non-condensing)
Power supply	DC 12V,1/1.5A
Power consumption	≤10W
Dimension	205mm×140mm×37mm(L×W×H)
Net weight	0.34Kg

Application

FTTO (office), FTTD (Desk), FTTH(Home), SOHO, video surveillance and others

Packing Contents

G/EPON DUAL MODE ONU 1GE+3FE +2POTS+2.4G WiFi+USB for FTTx Solution
