VSOL V3552E 48 Ports Ethernet Network Switch L3 Managed With 4SFP 10GE Uplink

VSOL V3552E 48 Ports L3 Managed Ethernet Network Switch with 4 SFP+ 10GE Uplink

Product Description

V-SOL V3552E is a new-generation smart switch developed for carrier IP MAN and enterprise networks. Based on the new high-performance hardware and the ROS platform, V35XX supports ACL, selective QinQ, 1:1 and N:1 VLAN switching, Ethernet OAM, carrier-level QoS, industry-level 10G Ethernet ring, etc.

V3552E provides 4 * 10GE/GE (SFP+) uplink ports, 48x10/100/1000Mbps LAN ports, which can meet the requirements of Gigabit access or convergence network.

Key Feature of V35xx Series Switch:

Carrier-Level High Reliability Layer-3 Routing Functions
Varied Service Characteristics Versatile IPv6 Solution Complete Security Mechanism
Supports Maximum 48 GE TX Ports and 4 10GE SFP+ Uplink Ports
Advanced Hardware Architecture and Industry-leading Port Density

Outstanding Solution, High Quality

Adopt the industry's advanced BCM solution and highly reliable carrier-class design.
Great performance: End-to-end data can be transmitted at non-blocking full wire speed

Software Features:

Spanning Tree

802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP)
BPDU guard, root guard and loopback guard

Multicast

Support IGMP v1/v2/v3, IGMP Snooping, IGMP Fast Leave, MVR, IGMP ﬁlter

QoS

CAR, HQoS, MAC/IP/TCP/UDP/ VLAN/ COS/ DSCP/ TOS based QoS, 802.1P/ DSCP priority re- labeling, SP, WRR, and “SP+WRR”, Tail-Drop, WRED, ﬂow monitoring and trafﬁc shaping

DHCP

DHCP server/relay/client
DHCP snooping/option82

IPv6

ICMPv6, DHCPv6, ACLv6 and IPv6 Telnet
IPv6 neighbor discovery, Path MTU discovery
MLD V1, MLD snooping
IPv6 Static Routing, RIPng, OSPFv3
Manual tunnel, ISATAP tunnel,6 to 4 tunnel

Reliablity

Static/LACP link aggregation, Interface backup
EAPS and ERPS
ISSU uninterrupted system upgrade
BVSS, ups to 16-units per stack
VRRP, UDLD

Security

Port isolation, Port security, and “IP+MAC+port” binding,MAC sticky DAI & IP source guard PPPoE+
IEEE 802.1x, AAA, Radius and BDTacacs+
L2/L3/L4 ACL ﬂow identiﬁcation and ﬁltrationAnti-attack from DDoS,TCP’s SYN Flood, UDP Flood, etc
Broadcast/multicast/unknown unicast storm-control
MD5, SHA-256, RSA-1024, AES256,etc.

VLAN

4K Active VLAN, QinQ & Selective QinQ, GVRP, Private VLAN & Voice-VLAN

Technical Parameters

Parameter			V3528E	V3528EF	V3528-P	V3552E
Interfaces			24GE (RJ45)+ 410GE/GE (SFP+)	16GE (SFP) + 8GE (SFP/RJ45 combo) + 4*10GE/GE (SFP+)	24GE (RJ45, POE) + 410GE/GE (SFP+)	48GE (RJ45) + 410GE/GE (SFP+)
Console(RJ45)			1	1	1	1
Backplane(Gbps)			128	128	128	336
Forwarding rate(Mpps with 64 bytes)			96	96	96	148
Chassis		Dimensions (WxDxH)(mm)	440x180x44	440x280x44	440x210x44	440x280x44
Chassis		Weight (KG)(empty)	2.6	4	3	4.3
Package		Dimensions (WxDxH)(mm)	500x320x80	576x448x94	555x295x88	576x448x94
Package		Weight(KG)	3.9	5.2	4.1	5.5
Power consumption		no-load	＜22W	＜18W	＜25W	＜25W
Power consumption		full-load	35W	＜38W	＜408W	＜40W
Power supply	AC:100V-240V, 50-60Hz		45W	45W	410W	45W
POE power budgest			/	/	370W	/
Total output BTU(1000BTU/H=293W)			153.58	153.58	1392.49	153.58
Fan number			/	2	2	2
Noise@25℃(dBA)			0	45	37.5	45
MTBF(H)			＞50,000	＞50,000	＞50,000	＞50,000
Forwarding mode			Store-forward	Store-forward	Store-forward	Store-forward
Flash(MB)			32	32	32	32
DRAM(MB)			256	256	256	256
MAC			16K	16K	16K	32K
Buffer size(MB)			1.5	1.5	1.5	1.5
Interface VLAN			64	64	64	64
Routing table			2040	2040	2040	2040
Jumbo frame			9K	9K	9K	9K
