V2801SD-1GPD Dual Mode ONU ABS Plastic 1GE Secure Reverse PoE ONU FTTx Solutions

V2801SD-1GPD Dual Mode ONU Most Popular 1GE Secure With Reverse PoE

Product Description

V2801SD-1GPD GPON 1GE ONU meets telecom operators FTTO (office), FTTD (Desk), FTTH(Home) broadband speed, SOHO broadband access, video surveillance and other requirements and design a GPON Gigabit Ethernet products.

V2801SD-1GPD GPON 1GE Safe ONU, It can also be applied to a wide temperature environment, and also has a powerful firewall function.The box is based on the mature Gigabit GPONtechnology, highly reliable and easy to maintain, with guaranteed QOS for different service. And it is fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.

Interface Description

Port Type	Function
PON	Connect PON port with internet by SC/UPC type, single mode optical fiber cable.
LAN	Connect device with ethernet port by RJ-45 cat5 cable. Optional support PD(reverse POE) function.
RST	Press down reset button and keep1-5seconds to make the device restart and recover from the factory default settings.
DC12V	Connect with power adapter.

Key Features

Software Key Feature
EPON/GPON mode	Dual mode , Can access EPON/GPON OLTs.
Software mode	Bridging mode and Routing mode.
Abnormal protection	Detecting Rogue ONU, Hardware Dying Gasp.
Firewall	DDOS, Filtering Based on ACL/MAC/URL.

Indicators

LED	Mark	Color	Status	Description
system	SYS	Green	On	Device is powered on and starting.
			Blink	Device is running normally.
			Off	Device is powered off.
Optical signal state	REG	Yellow	Blink	Device is not registered to the PON system.
		Green	Blink	Device is being registered.
		Green	On	Device is registered to the PON system.
Interface	LINK/ACT	Green	On	Port is connected properly .
			Off	Port connection exception or not connected.
			Blink	Port is sending or/and receiving data.
