HG323RGWT GPON ONU 1GE +1FE +1FXS + CATV + WIFI Router For Huawei
ZTE
Product Description
HG323RGWT is based on mature and stable, cost-effective EPON/GPON technology,
high reliability, easy management, configuration flexibility and
good quality of service (QoS) guarantees to meet the technical
performance of IEEE802.3ah and ITU-TG.984.x , China Telecom
EPON/GPON equipment technical requirements and other
specifications.
HG323RGWT G/EPON 1GE+1FE+WiFi+CATV ONU meets telecom operators FTTO
(office), FTTD (Desk) ,FTTH(Home) broadband speed, SOHO broadband
access, video surveillance and other requirements to design an
EPON/GPON Gigabit Ethernet products.
GPON/EPON +1GE+1FE+1POTS+WiFi+CATV
Key Features
- Dual Mode( can access gpon/epon olts ).
- Plug and play, features auto-detecting, auto-configuration, and
auto firmware upgrade, etc.
- Integrated OMCI remote configuration and maintenance function.
- Support rich QinQ VLAN functions and IGMP Snooping multicast
features.
- Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.
- Support 802.11n WiFi(2T2R) function.
- Support NAT, Firewall function.
- Support IPv4 and IPv6 dual stack.
- Integrated line testing compliant with GR-909 on POTS.
Application
Telecom operators FTTO (office), FTTD (Desk) ,FTTH(Home) broadband
speed, SOHO broadband access, video surveillance
Function Description
Data Service Functions
Full speed non-blocking switching.
2K MAC address table.
64 full range VLAN ID.
Support QinQ VLAN, 1:1 VLAN, VLAN reusing, VLAN trunk, etc.
Integrated port monitoring, port mirroring, port rate limiting,
port SLA, etc.
Support auto polarity detection of Ethernet ports (AUTO MDIX).
Integrated IEEE802.1p QoS with four level priority queues.
Support IPv4 IGMP snooping and IPv6 MLD snooping.
Support bridge, router and bridge/router mixed mode.
POTS Service Functions
Call protocol: SIP(IMS compatible), seamless compatible with all
popular call agent.
Integrate heartbeat function and support active/standby call agent.
Voice coding: ITU-T G.711/G.723.1(5.3K/6.3Kbit/s)/G.729,
auto-negotiate with call agent.
Echo cancellation exceeding ITU-T G.165/G.168-2002, up to 128ms
tail length.
Support high/low speed fax, bypass fax, and T38 fax.
Support high speed MODEM(56Kbps) dial access.
Support RFC2833 and redundant RFC2833, difference rings, MD5
authentication, call forward, call waiting, hot-line call, alarm
clock, and all kinds of value-added voice service.
Multi-party conferencing.
Line testing according to GR-909.
IP address assignment: dynamic PPPoE/DHCP Client and static IP.
Support WEB, CLI,IVR,TR069.
Call loss less than 0.01%.
WIFI Service Functions
Integrated 802.11b/g/n, 300Mbps, 2T2R.
Support 128 connections.
Support WEP and WPA/WPA2 security protocols.
Order Information
| Product model | Product specification | Chipset | SDRAM Memory |
| HG323RGWT | 1 G/EPON+1GE+1FE+1POTS+WiFi+CATV | Realtek | 64MB |
